Altium Vaults

Article by:
Date Published:
Last Modified:


Vaults are for storing design data.

Depiction of the Altium vault.

Depiction of the Altium vault.

Personal Vault

The personal vault doesn’t allow more than 3 connections at once.

Adding Components

Components are best added to a vault from a component library (.CmpLib extension). Note that component libraries do NOT have the ability for “visible by default” component parameters!
